Bug #16080
open
Issues Upgrading from 24.03 to 24.11 SG-1100 Atheros 9280
0%
Description
I receive the below crash when upgrading my SG-1100 to 24.11. See attached upgrade log.
Refer to: https://forum.netgate.com/topic/195367/issues-upgrading-from-24-03-to-24-11-sg-1100-atheros-9280
pcib0: <Marvell Armada 3700 PCIe Bus Controller> mem 0xd0070000-0xd008ffff irq 5 on simplebus0
pcib0: link up
pci0: <OFW PCI bus> on pcib0
ath0: <Atheros 9280> at device 0.0 on pci0
Fatal data abort:
x0: 0x0000000000000000
x1: 0x00000000e8000000
x2: 0x000000000000704c
x3: 0x0000000000000003
x4: 0xffff000000dcee88 (ar5212Modes + 0x0)
x5: 0xffff0000898f4978 ($d.6 + 0x86b61f30)
x6: 0x0000000000000000
x7: 0x0000000000000000
x8: 0xffff000000b6a4b0 (generic_bs_w_4 + 0x0)
x9: 0xffff000000193c2c (ar9280DisablePCIE + 0x0)
x10: 0x000000000000001b
x11: 0x0000000000000000
x12: 0x0000000000000000
x13: 0x0000000000000000
x14: 0x0000000000000000
x15: 0x0000000000000000
x16: 0xffff000000b6a6d0 (bounce_bus_dma_tag_create + 0x0)
x17: 0x0000000000000000
x18: 0xffff0000022c9430 (initstack + 0x3430)
x19: 0xffff0000898f2000 ($d.6 + 0x86b5f5b8)
x20: 0x0000000000000003
x21: 0x00000000e8000000
x22: 0x000000000000704c
x23: 0xffff000002221b00 (memmap_bus + 0x0)
x24: 0xffff00008a81b000 ($d.6 + 0x87a885b8)
x25: 0x000000000000002a
x26: 0xffff0000898f6000 ($d.6 + 0x86b635b8)
x27: 0x0000000000004568
x28: 0xffff000002147c50 (AR9280_chip + 0x0)
x29: 0xffff0000022c9430 (initstack + 0x3430)
sp: 0xffff0000022c9430
lr: 0xffff000000167dec (ath_hal_reg_write + 0xbc)
elr: 0xffff000000b6a4b8 (generic_bs_w_4 + 0x8)
spsr: 0x00000000800000c5
far: 0x00000000e800704c
esr: 0x0000000096000044
panic: vm_fault failed: 0xffff000000b6a4b8 error 1
cpuid = 0
time = 1
KDB: enter: panic
[ thread pid 0 tid 100000 ]
Stopped at kdb_enter+0x48: str xzr, [x19, #2944]
db>
Files
No data to display
